4G LTE Mobile WiFi Pocket Hotspot MIFI Router Modem build-in 3800mAh battary special for Europe asia africa

FDD-LTE

Band FDD
B1/3/7/8/20/28

TDD

B38/40/41

Item

Sub Item

SPEC

Note

Hardware

Size

99*60*18mm

Battery capacaity

3200mAh

LCD/LED

LED

Color

White
and Black

WAN

4G Band

FDD-LTE

Band
FDD B1/3/7/8/20/28

TBD/Frequency is customized

TDD

B38/40/41

WCDMA

B1/8

Power Level

FDD LTE

Power
Class 3（23 +/-2dBm）

Sensitivity

FDD LTE

-93
dBm(20MHZ)

Data Rate

FDD-LTE

3GPP
R9 ,Category 4, DL 150MbpsUL50Mbps

LAN

WIFI

WIFI BAND

2.4G Frequency

WIFI Standard

IEEE 802.11 b/g/n/ax

WIFI Highest Rate

WIFI6 300Mbps

Numerof WIFI
Connections

12

System

2G/3G/4G setup

Network Selection

Manual,
Auto

Supported

Setup by user

Interoperability

TDD-LTE
& TD-SCDMA，TD-SCDMA &
GSM, TDD-LTE & UMTS, FDD-LTE & TD-SCDMA, FDD-LTE $ UMTS, UMTS &
GSM

Supported

SMS

SMS
over SGs Func at LTE

Supported

SMS’s receiving and reading

Supported

APN setup

APN
setup and revise

Supported

PIN Func

PIN:Save,
revise, lock,unlock

Supported

DM

CMCC
DM

Supported

Modem Func

Conn
to PC by USB

Supported

Automatically connect reconstructed

Can
automatically reconnect to network after off-network in data using

Supported

WIFI setup

Protocol

Max
users over 10

Supported

DHCP client / server, you can set whether to
activate the DHCP service assigns IP addresses starting and ending addresses,
set the gateway address;
Support client list: Displays all the DHCP server to obtain IP address of
the host, including MAC address, IP address obtained

Supported

Support terminal IP address, SSID,
communication channel, security type, the administrator account and password
factory setting

Supported

Support SSID and channel settings: Set SSID,
communication channel (frequency band WiFi settings, select the range of WiFi
support of the band all the available channels), WIFI function on/off, and
the SSID broadcast on/off

Supported

WPA-PSK& WPA2-PSK

Supported

Support
MAC and IP filtering

Supported

Other setup

Driver
setup

With
the PC operating system automatically recognizes, supports drivers installed
automatically

Partly
Supported

Web Server

WEB
UI

Supported

Administrator password configuration

Terminal
preset default administrator password, supports password changes

Supported

SW update

Support
local upgrade the firmware of the terminal

Supported

Time setup

Set
user location’s time

Supported

Recovery

Support
the terminal restore all settings to the factory default state

Supported

Reboot

Reboot
by SW

Not
Supported

Online help

This
menu item provides the user with the help of the course, descriptive
information

Supported

Power features

working
Voltage

Battery
voltage：3.5-4.2V

Voltage fluctuations

3.5-4.2V DC

working Current

TBD

Mobile Power Supplier

supported， output 1A

Environmental Characteristics

Operating
Temperature

0℃～+45℃

Extreme working temperature

-10℃～+60℃

Storage Temperature

-30℃～+80℃

Relative humidity

5%~
85% （非凝结）

Structure

Weight

TBD

I/O

Micro
USB

Platform

Qualcomm
9607

WIFI Chip

AIC8800DW

Battery

3200mAh

LTE SIM

Single

T-Flash Card

NO

Size

99*60*18mm

Port

LTE
SIM

3GPP
31.101 and 31.102 standard

USB

Micro-USB
C

Key

Power

LED

Not
supported

PC OS

Win7/WinXP

Supported

MAC OS

Supported

Windows8/10/11

Supported

Android

Supported
